Elevate Your Work

• High-Lift Plus configuration provides an additional 24 inches of hinge-pin height over standard lift height and 12 inches over the High-Lift model. All three lift heights feature near-parallel lift.

EH Controls

• Easily control up to six functions without removing your hand from the ergonomically designed joystick. Two industry-exclusive multifunction buttons can each be programmed to handle any of 10 functions selected through the monitor including bucket vibrate and electrohydraulic (EH) Precision mode.

Buckets & Linkage

• Featuring bucket and linkage designs that improve load leveling, material retention, and visibility, these loaders yield more productivity and performance than previous models.
• A wide selection of enhanced production buckets with integrated spill guards, curved side cutters, and impressive rollback delivers elevated bucket-fill performance and material retention compared to earlier offerings.

Comfortable Cab

• Make yourself at home in an operator station featuring more legroom, an improved HVAC system, additional storage, and a more adjustable seat than previous models.
• Large seven-inch in-cab display with easy-on-the-eyes clarity enables intuitive push-button access to key info.

Same-Side Ground-Level Service

• All daily service points including fuel refill are conveniently grouped at ground level on the left side of the machine for easy access.

Specifications

• CAPACITIES - Alternator Output, Amp: 100
• CAPACITIES - Axle - Front, ltr (gallons (US)): 16.6 (4.375)
• CAPACITIES - Axle - Rear, ltr (gallons (US)): 18 (4.75)
• CAPACITIES - Breakout - Bucket , kgf (lbf): 13166 (29026)
• CAPACITIES - Fuel Tank, ltr (gallons (US)): 298 (79)
• CAPACITIES - Heaped Capacity, m³ (yd³): 2.3 (3)
• CAPACITIES - Hydraulic Tank, ltr (gallons (US)): 82.1 (21.7)
• CAPACITIES - Largest bucket capacity, m³ (yd³): 2.5 (3.25)
• CAPACITIES - Pump Flow - 1, lt/min (gallons (US) / min): 220 (58)
• CAPACITIES - Pump Type: Piston
• CAPACITIES - Ride Control System: Optional
• CAPACITIES - Smallest bucket capacity, m³ (yd³): 2.3 (3)
• CAPACITIES - System Pressure, bar (PSI): 251.66 (3650)
• CAPACITIES - System Voltage, V: 24
• CAPACITIES - Transmission, ltr (gallons (US)): 21 (5.55)
• DIMENSIONS - Ground clearance, mm (inches): 400 (15.7)
• DIMENSIONS - Height - Over Cab, mm (ft/in): 3330 (10 ft 11 in)
• DIMENSIONS - Height - Pivot Pin, mm (ft/in): 3890 (12 ft 9 in)
• DIMENSIONS - Length - Including Bucket, mm (ft/in): 7490 (24 ft 7 in)
• DIMENSIONS - Reach - At 2130mm 45° Dump, mm (ft/in): 1510 (4 ft 11 in)
• DIMENSIONS - Turning Circle - Maximum, mm (ft/in): 11580 (38 ft )
• DIMENSIONS - Wheelbase, mm (ft/in): 2930 (9 ft 7 in)
• DIMENSIONS - Width Over tires - Std, mm (ft/in): 2546 (8 ft 4 in)
• DRIVELINE - Displacement, ltr (Inches³): 6.8 (414)
• DRIVELINE - Emission Rating: Tier 4 / Stage V
• DRIVELINE - Engine Manufacturer : John Deere
• DRIVELINE - Engine Model: PowerTech PVS 6068
• DRIVELINE - Engine Output - Net, kW (hp): 123 (166)
• DRIVELINE - Front Differential Type: Locking
• DRIVELINE - Parking Brake - Type: Wet Multi Disc
• DRIVELINE - Rated Speed, rpm: 1700
• DRIVELINE - Rear Differential Type: Open
• DRIVELINE - Service Brake - Actuation: Hydraulic
• DRIVELINE - Service Brake - Location: All Wheels
• DRIVELINE - Service Brake - Type: Wet Disc
• DRIVELINE - Tire size - Standard: 20.5 R25
• DRIVELINE - Torque Rise, %: 47
• DRIVELINE - Torque, Nm (lbf / ft): 740 (546)
• DRIVELINE - Transmission Type: Powershift
• WEIGHTS - Operating Weight, kg (lbs): 13844 (30520)

Features

• Operating Weight: 13 844-13 879 kg (30,520-32,598 lb.)
• Engine Net Power: 123 kW (166 hp)
• Bucket Capacity: 1.9-4.0 m3 (2.5&-5.25 cu. yd.)
