John Deere 624 P-Tier Mid-Size Wheel Loader
| Make | John Deere |
| Model | 624 P-Tier |
| Type | Mid-Size Wheel Loaders |
How can we help?
Description
- Net Power: 143 kW (192 hp) at 1,600 rpm
- Operating Weight: 15 747–15 790 kg (34,715–34,810 lb.)
- Bucket Capacity: 1.9–4.0 m3 (2.5–5.25 cu. yd.)
Models
Comfortable Cab
- Make yourself at home in an operator station featuring more legroom, an improved HVAC system, additional storage, and a more adjustable seat than previous models.
- Large seven-inch in-cab display with easy-on-the-eyes clarity enables intuitive push-button access to key info.
EH Controls
- Easily control up to six functions without removing your hand from the ergonomically designed joystick. Two industry-exclusive multifunction buttons can each be programmed to handle any of 10 functions selected through the monitor including bucket vibrate and electrohydraulic (EH) Precision mode.
Buckets & Linkage
- Featuring bucket and linkage designs that improve load leveling, material retention, and visibility, these loaders yield more productivity and performance than previous models.
- A wide selection of enhanced production buckets with integrated spill guards, curved side cutters, and impressive rollback delivers elevated bucket-fill performance and material retention compared to earlier offerings.
Same-Side Ground-Level Service
- All daily service points including fuel refill are conveniently grouped at ground level on the left side of the machine for easy access.
Elevate Your Work
- High-Lift Plus configuration provides an additional 24 inches of hinge-pin height over standard lift height and 12 inches over the High-Lift model. All three lift heights feature near-parallel lift.
Specifications
- CAPACITIES - Alternator Output, Amp: 130
- CAPACITIES - Axle - Front, ltr (gallons (US)): 22 (5.75)
- CAPACITIES - Axle - Rear, ltr (gallons (US)): 17 (4.5)
- CAPACITIES - Breakout - Bucket , kgf (lbf): 13605 (29994)
- CAPACITIES - Fuel Tank, ltr (gallons (US)): 299 (79)
- CAPACITIES - Heaped Capacity, m³ (yd³): 2.7 (3.5)
- CAPACITIES - Hydraulic Tank, ltr (gallons (US)): 102.8 (27.2)
- CAPACITIES - Largest bucket capacity, m³ (yd³): 2.9 (3.75)
- CAPACITIES - Pump Flow - 1, lt/min (gallons (US) / min): 261 (69)
- CAPACITIES - Pump Type: Piston
- CAPACITIES - Ride Control System: Optional
- CAPACITIES - Smallest bucket capacity, m³ (yd³): 2.7 (3.5)
- CAPACITIES - System Pressure, bar (PSI): 248.21 (3675)
- CAPACITIES - System Voltage, V: 24
- CAPACITIES - Transmission, ltr (gallons (US)): 27 (7.125)
- DIMENSIONS - Ground clearance, mm (inches): 384 (15.1)
- DIMENSIONS - Height - Over Cab, mm (ft/in): 3400 (11 ft 2 in)
- DIMENSIONS - Height - Pivot Pin, mm (ft/in): 3960 (13 ft )
- DIMENSIONS - Length - Including Bucket, mm (ft/in): 7760 (25 ft 6 in)
- DIMENSIONS - Reach - At 2130mm 45° Dump, mm (ft/in): 1590 (5 ft 2 in)
- DIMENSIONS - Turning Circle - Maximum, mm (ft/in): 12040 (39 ft 6 in)
- DIMENSIONS - Wheelbase, mm (ft/in): 3090 (10 ft 1 in)
- DIMENSIONS - Width Over tires - Std, mm (ft/in): 2657 (8 ft 8 in)
- DRIVELINE - Displacement, ltr (Inches³): 6.8 (414)
- DRIVELINE - Emission Rating: Tier 4 / Stage V
- DRIVELINE - Engine Manufacturer : John Deere
- DRIVELINE - Engine Model: PowerTech PVS 6068
- DRIVELINE - Engine Output - Net, kW (hp): 143 (192)
- DRIVELINE - Front Differential Type: Locking
- DRIVELINE - Parking Brake - Type: Wet Multi Disc
- DRIVELINE - Rated Speed, rpm: 1700
- DRIVELINE - Rear Differential Type: Open
- DRIVELINE - Service Brake - Actuation: Hydraulic
- DRIVELINE - Service Brake - Location: All Wheels
- DRIVELINE - Service Brake - Type: Wet Disc
- DRIVELINE - Tire size - Standard: 20.5 R25
- DRIVELINE - Torque Rise, %: 58
- DRIVELINE - Torque, Nm (lbf / ft): 923 (681)
- DRIVELINE - Transmission Type: Powershift
- WEIGHTS - Operating Weight, kg (lbs): 15747 (34715)
Features
- Bucket Capacity: 1.9-4.0 m3 (2.5-5.25 cu. yd.)
- Operating Weight: 15 747-15 790 kg (34,715-34,810 lb.)
- Engine Net Power: 143 kW (192 hp)
